Modular Semi-Anechoic Chamber (MSAC)
No.1 Share in JAPAN
Modular Semi-Anechoic Chamber is used for measuring sound power in vehicles, NVH ( Noise, Vibration, and Harshness) applications, electrical products, and more..
Recent years, there has been a growing demand for VSAC ( Vehicle Semi-Anechoic Chamber ).
Sonora designs from scratch based on ISO standards or measurement methods specified by each user.
* Sound absorption layer on 5 faces (Walls, ceiling)
All components of the semi-anechoic chamber body are manufactured in Japan.
Products produced by the latest processing machines and skilled craftsmen ensure high precision.
The semi-anechoic chamber consists of steel sound insulation panels and frames as its basic structure.
Due to its compact and modular nature, on-site construction is easy, and dismantling and relocation are also possible.
The sound insulation panels and absorption wedges are original designs by Sonora.
Compared to other companies, they are high-performance yet thin, space-saving, and lightweight.
It is also competitively priced compared to other companies.
Various facilities such as wind tunnel testing machines, constant temperature and humidity equipment, equipment for transportation, and chassis dynamometers can be added.
We can propose sets with acoustic measurement instruments.
We handle measurement instruments from companies such as Brüel & Kjær, GRAS, Siemens, and others.
MODELS / PRICES
The specifications are just for reference, we customize from scratch.
There are 3 types of specifications. But basically, we’ll design from scratch, according to the size, measurement method and workability of the user’s acoustic measurement object. We can meet all kinds of requests, such as installing a crane, flattening the bottom of the door so that there is no step when carrying in, controlling temperature and humidity inside the chamber, and conducting a wind tunnel test.
Modular Semi-Anechoic Chamber (MSAC)
| Type | Wedge | Effective (mm) | External Dimensions (mm) | Price |
|---|---|---|---|---|
| X-1 without floor | HV02W | W2000 × L2400 × H2450 | W2700 × L3100 × H2800 | Please contact us |
| X-1 with floor | HV02W | W2000 × L2400 × H2450 | W2700 × L3100 × H2900 | |
| X-2 without floor | HV02W | W2400 × L3000 × H2450 | W3100 × L3700 × H2800 | |
| X-2 with floor | HV02W | W2400 × L3000 × H2450 | W3100 × L3700 × H2900 | |
| X-3 without floor | HV02W | W3000 × L3600 × H2450 | W3700 × L4300 × H2800 | |
| X-3 with floor | HV02W | W3000 × L3600 × H2450 | W3700 × L4300 × H2900 | |
| S-1 without floor | T-250 | W2000 × L2400 × H2450 | W2700 × L3100 × H2800 | |
| S-1 with floor | T-250 | W2000 × L2400 × H2450 | W2700 × L3100 × H2900 | |
| S-2 without floor | T-250 | W2400 × L3000 × H2450 | W3100 × L3700 × H2800 | |
| S-2 with floor | T-250 | W2400 × L3000 × H2450 | W3100 × L3700 × H2900 | |
| S-3 without floor | T-250 | W3000 × L3600 × H2450 | W3700 × L4300 × H2800 | |
| S-3 with floor | T-250 | W3000 × L3600 × H2450 | W3700 × L4300 × H2900 | |
| H-1 without floor | T-500 | W2000 × L2400 × H2450 | W3200 × L3600 × H3050 | |
| H-1 with floor | T-500 | W2000 × L2400 × H2450 | W3200 × L3600 × H3150 | |
| H-2 without floor | T-500 | W2400 × L3000 × H2450 | W3600 × L4200 × H3050 | |
| H-2 with floor | T-500 | W2400 × L3000 × H2450 | W3600 × L4200 × H3150 | |
| H-3 without floor | T-500 | W3000 × L3600 × H2450 | W4200 × L4800 × H3050 | |
| H-3 with floor | T-500 | W3000 × L3600 × H2450 | W4200 × L4800 × H3150 | |
| Free type | Other designs: it’s inexpensive out of those specifications. So please contact us | |||
SPECIFICATION
Top-class sound insulation performance is guaranteed.
The sound insulation performance of the anechoic room is unrivaled compared with other companies. The background noise in the semi-anechoic chamber can even reach to 0 dB varying depending on the installation environment. An advanced acoustic measurement space can be realized by introducing our semi-anechoic chamber.
Sound Insulation level (Transmission Loss) / dB
| Sound Insulation (Transmission Loss) / dB | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Hz | 63 | 125 | 250 | 500 | 1K | 2K | 4K | 8K | |
| Guarantee Value of Sound Insulation | X | （20） | 30 | 36 | 40 | 49 | 53 | 55 | 54 |
| S | （28） | 35 | 41 | 45 | 51 | 55 | 57 | 56 | |
| H | （32） | 40 | 46 | 50 | 56 | 60 | 62 | 61 | |
| Actual Value of Sound Insulation | X | 32.6 | 49.4 | 62.4 | 74.5 | 77.8 | 83.1 | 81.5 | 81.5 |
| S | 33.4 | 50.3 | 59.0 | 63.1 | 64.9 | 68.6 | 78.0 | 84.2 | |
| H | 41.9 | 50.8 | 60.1 | 71.3 | 75.1 | 77.3 | 79.9 | 86.0 | |
PARTS LIST
Standard
- Single swing sound insulation door: Inner wall sound absorption layer
- Floor panel + reflection plate (Excluding cases without floor)
- Vibration isolation layer
- Utility pipe diameter 65 + inside and outside sound insulation cover
- Microphone hanging hook
- Air supply diffraction silencer
- Exhaust diffraction silencer
- Complete documents (drawings, specifications, etc.)
- Light bulb type LED lighting
- Outlet 100V-3P-2 ports Indicator light 10W “In use” text
- Sirocco fan + flexible silencer
- Switch box, distribution board
- 2 Next side wiring work
Option
- Air conditioning equipment Monitor
- Signal light
- Sound Absorption BNC Shelf Intercom
- Gas Alarm
- Fire Alarm etc.
OTHERS
- All anechoic room structural materials are using non-combustible materials
- With completed books
- We will change the dimensions of the anechoic chamber and adjust the sound absorption performance as well according to the installation layout.
- Can be removed, modified.
- The lead time depends on the operation of the factory, so please contact us.
Materials Download
You can download the PDF file from here
SONORA’S ADVANTAGES
Price lower than Competitors
We pride ourselves on offering top-notch products right in our own factory, cutting out the middleman and ensuring that you get the best value for your money. When you compare quotes, you’ll find that our prices are consistently lower than our competitors. We guarantee the same specifications and warranty terms as the competitors. So you get the same great product.
First penguin in the industry to introduce “Acoustic Performance Guarantee System”
Since our establishment, Sonora has remained steadfast in our commitment to ensuring the superior acoustic performance of all our products. Through meticulous verification measurement tests, we guarantee that our stated values are substantiated, thus eliminating any concerns regarding insufficient sound reduction, even in spaces equipped with Anechoic Chambers. Sonora stands firm in our dedication to fulfilling our responsibility as a leading sound insulation specialist company, delivering unparalleled quality and reliability to our esteemed clients.
Second-to-None Product Performance
Sonora’s unwavering commitment to research and development drives continuous enhancements to our proprietary sound control technology, which constitutes the foundation of nearly all our products. Since our inception, we have consistently expanded our expertise through the resolution of diverse noise challenges, further solidifying our proven track record and distinctive knowledge base.
Choose Sonora for unparalleled quality and value in acoustic measurement solutions.
