Automatic-Door Anechoic Enclosure for Automotive Parts Manufacturer

AEB

We delivered an automatic-door anechoic enclosure for an automotive parts manufacturer.

External Dimensions

Equipped with vibration-isolating mounts to reduce interference from surrounding equipment

Approx. external sizeW 1400 × D 1665 × H 2470 mm
Approximate weight750 kg
Base frame100 × 100 × 3.2 (baked finish)

Main Structure

  • Multilayer metal sound-insulation structure (ivory baked finish)
  • Acoustic absorption system using AST absorbers + rear absorption layer

Automatic Door System

  • Door drive: electric cylinder
  • Air cylinder for door sealing
  • Sealing handle
  • Hinges
  • Shaft silencer

Floor & Base Structure

  • Vibration-isolating mounts
  • High-rigidity base frame (100 × 100 × 3.2)
  • Structure designed for maintainability and ease of servicing

Internal Features & Accessories

  • Table (PL-9):
    ・2 × φ60 through-holes
    ・1 × φ50 through-hole
    ・8 × M8 / 9 × M6 tapped holes
  • Acoustic mat
  • Transport eyebolts
  • Cable penetration holes: 2 × φ55 (with sound-insulation covers)
  • Operation handle
